Er70s6 Mild Steel TIG Welding Rod Arc Welding Wire

Looking for high-quality Er70s6 Mild Steel TIG Welding Rod Arc Welding Wire? Look no further! We are a factory specializing in producing top-grade welding rods. Get yours today!
Request a Quote

PRODUCTS DETAILS

Basic Info.

Model NO.
ER70S-6
TIG Wire Specification
2.0mm, 2.4mm, 2.5mm, 3.0mm
Trademark
TYUE
Origin
China
HS Code
722330000
Production Capacity
7500000tons/Year

Product Description

Wenzhou Tianyu Electronic Co., Ltd.

CO2 Mig & Tig Welding Wire ER70S-6 Gas Shielded

Welding Wire ER70S-6 -- Description:
ER70S-6 is a kind of mild steel copper coated welding wire, suitable for 100% CO2 and Argon& CO2 mixed gas protective welding with stable feasibility, good welding seams, less spatters and excellent welding process properties.

Welding Wire ER70S-6 -- Conform with:
GB/T ER50-6 DIN SG2 JIS YGW12
AWS ER70S-6 BS A18 EN G3Si1 CO2 and Argon& CO2 mixed gas protective welding with stable feasibility, good welding seams, less spatters
Main Characteristics ADVANTAGES:
1. Low welding costs.
2. High productivity and low electricity consumption.
3. Easy to operate. All-position welding.
4. Very low hydrogen content in the weld and lower nitrogen content. Excellent crack-resistance.
5. Little deformation after welding.
6. Wide applicability. Suitable for welding thin, medium and thick plates.

ER70S-6 MIG wire welding wire specification:
1. Type: CO2 wire/SG2 welding wire/ Mig wire/ GMAW wire/ Solid welding wire/ Gas shielded welding wire
2. Raw material: MIld steel/ Carbon steel
3. Surface-Copper coated / copper clad
4. Application : Co2 shielded welding, welding of mild steel material,Ship welding, Arc welding etc
5.Diameter:  0.8 0.9 1.0 1.2 1.6mm
6.Packing: 5Kg,15Kg 20kg spool, 100~350kg drum


ER70S-6 TIG wire welding wire specification::
1. Diameters: 2.0mm, 2.4mm, 2.5mm, 3.0mm
2. GB standard: GB ER50-6
3. AWS standard: AWS ER70S-6
4. Delivery time: 10days for 20ft container after order comfirmation
5. Surface treatment: Copper coated
6. Material: Low alloy steel
7...Packing: 5kg, 10kg precision layer wound/box. One spool/carton. 63cartons/wooden pallet.


Mig Wire Package Details
Specification Wire length Weight
Φ0.8~1.6mm

1M

 5kg, 10kg


Wire Chemical Composition(%)
C Mn Si P S Cr Ni Cu
0.06~0.15 1.40~1.85 0.80~1.15 ≤0.025 ≤0.035 - - ≤0.50



Deposited Metal Mechanical Properties

Yield Strength

σ0.2(Mpa)

Tensile Strength

σb(Mpa)

Elongation

δ5%

AKV Impact Energy

(J)(-40ºC)

≥420 ≥500 ≥22

≥90



Diameter of Wire(mm) Φ0.8 Φ1.0 Φ1.2 Φ1.6
 Welding Current(A) 40~140 50~220 80~350 120~450





Er70s6 Mild Steel TIG Welding Rod Arc Welding Wire
Er70s6 Mild Steel TIG Welding Rod Arc Welding Wire



Er70s6 Mild Steel TIG Welding Rod Arc Welding Wire
Er70s6 Mild Steel TIG Welding Rod Arc Welding Wire Er70s6 Mild Steel TIG Welding Rod Arc Welding Wire






Our services :

1:Good after sales service: Any small problem happening will be solved at the most prompt time.
2. We have many years of experience, we have specializing in fastener.
3. Specifications list is available upon your requirement.
4. Packing as your request before shipment.
5. High quality and competitive price.
6. Free sample

Er70s6 Mild Steel TIG Welding Rod Arc Welding Wire Er70s6 Mild Steel TIG Welding Rod Arc Welding Wire Er70s6 Mild Steel TIG Welding Rod Arc Welding Wire Er70s6 Mild Steel TIG Welding Rod Arc Welding Wire
Er70s6 Mild Steel TIG Welding Rod Arc Welding Wire Er70s6 Mild Steel TIG Welding Rod Arc Welding Wire
